Product Summary

PolyZen devices are polymer enhanced precision Zener
diode micro-assemblies that help protect sensitive
electronics from damage caused by inductive voltage
spikes, voltage transients, use of incorrect power supplies
and reverse bias.
The PolyZen micro-assembly incorporates a stable
Zener diode for precise voltage clamping and a
resistively non-linear, polymeric positive temperature
coefficient (PPTC) layer that responds to either diode
heating or overcurrent events by transitioning from a
low to high resistance state.
PolyZen devices help provide resettable protection
against damage caused by multi-watt fault events and
require only 0.7W power dissipation. In the event of
sustained high power conditions, the PPTC element of
the device “trips” to limit current and generate voltage
drop. This functionality helps protect both the Zener
and the follow-on electronics, effectively increasing the
diode’s power handling capacity.

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
ZEN056V130A24LS
ZEN056V130A24LS

TE Connectivity / Raychem

TVS Diodes - Transient Voltage Suppressors Poly Zen 1.3A 13

Data Sheet

0-1: $0.56
1-10: $0.55
10-100: $0.44
100-500: $0.38
ZEN056V130A24LS-TB
ZEN056V130A24LS-TB

TE Connectivity / Raychem

TVS Diodes - Transient Voltage Suppressors PolyZen Micro-Assem on Test Board

Data Sheet

0-1: $4.98
1-10: $3.57
10-100: $3.15
100-500: $3.12
