Product Summary

General Description
The AO3422 uses advanced trench technology to
provide excellent RDS(ON)
 and low gate charge. It
offers operation over a wide gate drive range from
2.5V to 12V. This device is suitable for use as a load
switch. Standard product AO3422 is Pb-free (meets
ROHS & Sony 259 specifications). AO3422L is a
Green Product ordering option. AO3422 and
AO3422L are electrically identical.

Features

Features
VDS (V) = 55V
ID = 2.1A  (VGS
= 4.5V)
RDS(ON)
< 160mΩ (VGS = 4.5V)
RDS(ON)
 < 200mΩ (VGS = 2.5V)

Diagrams



Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
AO3422
AO3422


MOSFET N-CH 55V 2.1A SOT23

Data Sheet

0-1: $0.35
1-25: $0.21
25-100: $0.17
100-250: $0.12
250-500: $0.10
500-1000: $0.08
