Product Summary

General Description
The AO7600 uses advanced trench
technology MOSFETs to provide excellent
RDS(ON)
 and low gate charge. The
complementary MOSFETs may be used
to form a level shifted high side switch, an
inverter, and for a host of other
applications. Both devices are ESD
protected. Standard Product AO7600 is
Pb-free (meets ROHS & Sony 259
specifications). AO7600L is a Green
Product ordering option. AO7600 and
AO7600L are electrically identical.

Features

Features
n-channel                        p-channel
VDS (V) = 20V                 -20V
ID = 0.9A (VGS=4.5V)      -0.6A (VGS=-4.5V)

RDS(ON)                                     RDS(ON)
< 300mΩ (VGS=4.5V)      < 550mΩ (VGS=-4.5V)
< 350mΩ (VGS=2.5V)      < 700mΩ (VGS=-2.5V)
< 450mΩ (VGS=1.8V)      < 950mΩ (VGS=-1.8V)
