Product Summary
General Description
The AO8822 uses advanced trench technology to
provide excellent RDS(ON)
, low gate charge and
operation with gate voltages as low as 1.8V while
retaining a 12V VGS(MAX)
rating. This device is suitable
for use as a uni-directional or bi-directional load
switch, facilitated by its common-drain configuration.
Standard Product AO8822 is Pb-free (meets ROHS
& Sony 259 specifications). AO8822L is a Green
Product ordering option. AO8822 and AO8822L are
electrically identical.
Features
Features
VDS (V) = 20V
ID = 7 A (VGS = 10V)
RDS(ON)
< 21mΩ (VGS = 10V)
RDS(ON)
< 24mΩ (VGS = 4.5V)
RDS(ON)
< 32mΩ (VGS = 2.5V)
RDS(ON)
< 50mΩ (VGS = 1.8V)
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 AO8822 |
|
MOSFET DUAL N-CH 20V 7A 8-TSSOP |
Data Sheet |
Negotiable |
|
||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||
 |
AO8800 |
Other |
|
Data Sheet |
Negotiable |
|
||||||
|
AO8801 |
Other |
|
Data Sheet |
Negotiable |
|
||||||
|
AO8802 |
Other |
|
Data Sheet |
Negotiable |
|
||||||
|
AO8803 |
|
MOSFET DUAL P-CH -12V -7A 8TSSOP |
Data Sheet |
Negotiable |
|
||||||
|
AO8804 |
|
MOSFET 2N-CH 20V 8A 8TSSOP |
Data Sheet |
|
|
||||||
|
AO8806 |
Other |
|
Data Sheet |
Negotiable |
|
||||||
